IEC 60811 Natural Air Exchange Aging Test Chamber
IEC 60811 Natural Air Exchange Aging Test Chamber Introduction:
Natural ventilation aging test equipment is mainly used for aging tests of polymer materials (plastic insulators or coatings for wires and cables) and heat resistance tests of electrical insulation materials and insulating components. It can also be used as a high-precision constant temperature drying oven for drying, baking, and heat treatment of items. However, it is not suitable for drying and testing flammable, explosive, or volatile materials that produce flammable or explosive substances. It is a commonly used testing equipment in industrial and mining enterprises, research institutions, universities, laboratories, and other departments.
IEC 60811 Natural Air Exchange Aging Test Chamber standard:
• IEC 60811-1-2
• IEC 60811-401
• VDE 0472
• GB/T 2951-2008
IEC 60811 Natural Air Exchange Aging Test Chamber Parameters:
IEC 60811 Natural Air Exchange Aging Test Chamber Feature:
● Temperature Range: Room temperature (approx. 25℃)～300℃;
● Temperature Fluctuation: ≤±0.5℃;
● Temperature Deviation: ≤±2℃;
● Heating Time: From room temperature to 300℃, approximately 50 minutes;
● Air Exchange Rate: 8～20 times/hour;
● Inner Chamber Dimensions: 450mm×450mm×500mm;
● Inner Chamber Material: SUS#304 stainless steel; Outer Chamber: Anti-static powder coating (white);
● Insulation Material: 100mm thick fiberglass wool filling on five sides, 60mm thick fiberglass wool filling at the bottom.
